Wholesale Products Portable Durable Hydraulic Power Punch Press Machine

Product Introduction:

Our high speed automatic punching machine removes the waste clearing step in traditional procedures and cuts the pattern paper directly. So it is a good machine which can not only largely reduce the consumption and manpower of worker.

Send Inquiry

Description

Technical Parameters

Our high speed automatic punching machine removes the waste clearing step in traditional procedures and cuts the pattern paper directly.

Main Technical Parameters

1. Punching mode: Online platen (applicable for roller paper).

2. Rated punching speed: 160-280cpm.

3. Applicable specification of original paper: 180-350g/m²

4. Roller paper and range of width: 360-850mm.

5. Diameter of roller paper: <1.5m.

6. Paper conveying speed: ＞35m/min (gap working).

7. Compressed air: 0.2m³/min, 0.5MPa-0.6MPa.

8. Length of guide roller surface: 900mm.

9. Power of main machine: 4kW.

10. Total power: 6kW.

11. Weight of machine: 3T.

12. Outer dimension (L×W×H): 2900mm×1400mm×1700mm.
