Work Principle
The sucking mouth will suck the paper which has been printed previously, from the paper bracket to the transportation chain, and then transport it to the forming mould. During the transportation, the paper will be spread with hot-melt glue. The position, length and quantity of thermal sol can be adjusted during the production process without stopping the machine. After the formation, the paper spread with glue will be automatically blown to be transported to the collection machine .The piling and counting are automatic. And the paper will be carried out according to the prearranged piling numbers without stopping the machine.
Power of Equipment
Main electric motor: 1 set, 380V, 2.2KW
Thermo sol heating device 1 set, 380V, 5.8KW
Vacuum pump motor 1 set, 380V, 2.2KW
Paper absorption blower 1 set, 220V, 180W
Cone discharging motor 1 set, 220V, 90W
Lubricating oil pump motor 1 set, 220V, 90W
Air compressor 1 set, 380V, 3-7.5KW
Technical Data
Model | JXG-A |
Production speed | Maximum speed 180 pieces per minute |
The raw material | Ordinary paper, composite aluminum foil paper or dry stencil paper, paper thickness 100-150gsm |
Minimum height | 140mm |
Maximum height | 210mm |
Angle | 17°~22° |
Power source | 380V, 50HZ |
Working power | 5.5KW |
Air consumption | 1m3/min, ≥0.7MPa |
Space required | 2mx2m |
Weight | 1000kg |
Main machine packing size (L×W×H) | 1300×1150×1900mm 1250×700×1100mm |
Electrical Part
No. | Name | Brand |
1 | Air switch | Siemens |
2 | Motor protector | Siemens |
3 | Hot-melt gluing system | Robatech (Swiss) |
4 | PLC | Siemens |
5 | Touch screen | China |
6 | Mini relay | Schneider |
7 | AC contactor | Siemens |
8 | Vacuum valve | SMC |
